2SK Series Advanced Two-Stage Water Ring Vacuum Pump | High-Efficiency Deep Vacuum Solutions

Upgrade your process with the 2SK series two-stage liquid ring vacuum pump, engineered for superior performance in high-vacuum regions. By utilizing a dual-impeller design, the 2SK series achieves deeper vacuum levels and more stable pumping speeds than single-stage models. Available as a stand-alone unit or as part of the 2SK-P1 series with an atmospheric jet pump for ultimate vacuum requirements in pharmaceutical and chemical processing.

Overview
Recommended Products

Description

Precision-Engineered 2SK Series Two-Stage Vacuum System

The 2SK series is specifically designed for industrial applications where a standard single-stage pump cannot meet the required vacuum depth. Its dual-stage compression cycle ensures maximum efficiency in the high-vacuum range, reducing energy consumption while maintaining a stable process environment.

Deep Vacuum Capability: Features a two-stage impeller design to reach vacuum levels far beyond standard SK models.
2SK-P1 High-Vacuum Unit: Integrated with an atmospheric jet pump to achieve an ultimate vacuum of -0.099 MPa (-750 mmHg).
Engineered for Volatiles: Ideal for handling gases with high moisture or condensable vapors without performance loss.
Low Maintenance Cost: Durable construction and simplified mechanical seals reduce long-term operational expenses.

2SK Series: High-Performance Two-Stage Vacuum Engineering

The 2SK Series, manufactured by Jinan Golden Bridge Precision Machinery Co., Ltd, is the heavy-duty evolution of the liquid ring vacuum pump. Unlike single-stage pumps, the 2SK series utilizes a dual-impeller system arranged in series. This architecture allows the second stage to further compress the discharge from the first stage, effectively achieving a much deeper ultimate vacuum and maintaining high pumping speeds even as the system approaches its limit.

Advantages

Why Choose the 2SK Stand-alone Pump?

Optimized Compression Ratio: The two-stage design significantly reduces backflow within the pump, ensuring a stable vacuum environment for precision processes.
Isothermal Safety: As a liquid ring pump, the compression is essentially isothermal (constant temperature), making it the safest choice for handling heat-sensitive or volatile vapors.
Durability for 24/7 Operations: Constructed with reinforced casting and high-grade mechanical seals, the 2SK is built for continuous industrial duty in harsh environments.

2SK-P1 Series: The Ultimate Deep Vacuum Unit

For specialized applications requiring an even deeper vacuum than a standard liquid ring pump can provide, we offer the 2SK-P1 High-Vacuum Unit. This system integrates the 2SK two-stage pump with an Atmospheric Jet Pump to push the boundaries of liquid ring technology.

The 2SK-P1 Advantage:

Extreme Vacuum Depth: Achieves an ultimate vacuum of -0.099 MPa (-750 mmHg), bridging the gap between standard liquid ring pumps and more complex vacuum technologies.
Cavitation Suppression: The jet pump provides a "buffer" that prevents the main 2SK pump from running in the cavitation zone during deep vacuum operation, extending the life of the impellers.
Plug-and-Play Integration: The 2SK-P1 is a pre-configured unit, ready to be integrated into your existing pharmaceutical or chemical processing line.

Specification Table

Technical Specifications (Standard Industrial Series)

MODEL	Air Flow (m³/min)		Ultimate vacuum Mpa (mmHg)	Motor Power (KW)	Speed (r/min)	Water Consumption (L/min)	Inlet Port (mm)	Outlet Port (mm)
MODEL	Max	Vacuum -700mmHg	Ultimate vacuum Mpa (mmHg)	Motor Power (KW)	Speed (r/min)	Water Consumption (L/min)	Inlet Port (mm)	Outlet Port (mm)
2SK-0.4	0.4	0.25	-0.096 (-720)	2.2	2860	3-5	G1"	G1"
2SK-0.8	0.8	0.5	-0.096 (-720)	3	2860	5-8	G1"	G1"
2SK-1.5	1.5	0.9	-0.097 (-730)	4	1440	10-15	40	40
2SK-3	3	2	-0.098 (-735)	7.5	1450	15-20	40	40
2SK-6	6	4		15	1460	25-35	70	70
2SK-12	12	8		22	970	40-50	100	100
2SK-20	20	14		45	740	60-80	125	125
2SK-30	30	20		55	740	70-90	125	125

Two-stage water ring vacuum pump with one-stage atmospheric pump

MODEL	Air Flow (m³/min)		Ultimate vacuum MPa (mmHg)	Motor Power (KW)	Speed (r/min)	Water Consumption (L/min)
MODEL	Suction Pressure 30 Torr (-730mmHg)	Suction Pressure 20 Torr (-740mmHg)	Ultimate vacuum MPa (mmHg)	Motor Power (KW)	Speed (r/min)	Water Consumption (L/min)
2SK-0.4P₁	0.28	0.24	-0.099 (-750)	2.2	2860	3-5
2SK-0.8P₁	0.56	0.48		3	2880	5-8
2SK-1.5P₁	1.05	0.9		4	1440	10-15
2SK-3P₁	2.1	1.8		7.5	1440	15-20
2SK-6P₁	4.2	3.6		15	1460	25-35
2SK-12P₁	8.4	7.2		22	970	40-50
2SK-20P₁	14	12		45	740	60-80
2SK-30P₁	21	18		55	740	70-90

Comprehensive Application Areas

The 2SK and 2SK-P1 series are essential for high-precision operations across various industries:

Pharmaceutical & Chemical: Vacuum distillation, evaporation, and concentration of heat-sensitive materials.

Food Processing: Large-scale vacuum drying and deaeration for shelf-life extension.

Advanced Manufacturing: Vacuum smelting, impregnation, and precision electronics manufacturing.

Textile & Wood Industry: High-efficiency drying systems for premium wood products and textile conditioners.
