Engineered for high-power fiber laser cutting machines (10kW - 30kW+). This heavy-duty 5-in-1 skid-mounted system features an oversized 1200L air receiver tank to guarantee zero pressure fluctuation, ensuring flawless and burr-free thick metal cutting.
Ultra-High Pressure: 16 Bar / 232 PSI (1.55 MPa) constant output.
Massive Storage: 1200L thickened air tank handles peak demands effortlessly.
Lens Protection: Integrated refrigerated dryer and multi-stage filters deliver 100% dry, oil-free air.
Powerful VSD Motor: 37 kW / 50 HP Permanent Magnet motor cuts energy costs by up to 35%.
Traditional air compressor setups often struggle with pressure drops during continuous high-power laser cutting, leading to ruined materials and damaged lenses. Our 5-in-1 Integrated System solves this by pairing a powerful 37kW (50HP) Permanent Magnet VSD compressor with a massive 1200L air receiver tank. This oversized storage buffer ensures absolute pressure stability at 16 Bar (232 PSI), delivering the ultra-dry and clean air required for cutting thick carbon steel, stainless steel, and aluminum without burrs.
Core System Advantages:
5-in-1 Space-Saving Design: Combines the Rotary Screw Compressor, 1200L Air Tank, Refrigerated Dryer, Precision Line Filters, and Smart Controller into one rugged skid.
Massive 1200L Buffer Capacity: Eliminates pressure pulsations and frequent motor starts, significantly extending the equipment's lifespan and ensuring smooth cutting edges.
Zero Bearing Maintenance: The direct-drive permanent magnet motor features a bearing-free design, preventing transmission power loss and eliminating the risk of motor bearing failures.
Intelligent PLC Protection: 24/7 automated monitoring of temperature, pressure, and voltage, with instant protective shutdown capabilities.
Beyond Laser Cutting: Versatile High-Pressure Applications While engineered to meet the extreme demands of fiber laser cutting, the robust 16 Bar (232 PSI) output and massive 1200L buffer tank make this 5-in-1 system the perfect pneumatic powerhouse for other rigorous industrial applications, including:
PET Blow Molding: Delivering clean, consistent high pressure for plastic bottle manufacturing.
Heavy-Duty Sandblasting & Painting: Providing ultra-dry air to prevent coating defects and rust.
High-Pressure Pneumatic Testing: Reliable constant pressure for pipeline and valve leak diagnostics.
Heavy Machinery Operation: Powering high-torque pneumatic tools in heavy duty repair facilities.
Technical Specifications (Heavy-Duty Laser Cutting Model)
| Model |
Power (KW) |
Pressure (Mpa) |
Air flow (m³/min) |
Noise db(A) |
Caliber |
Storage volume (L) |
Combination model |
| JKT-37YB | 37 | 1.55 | 2.8-3.6 | 70±2 | G1½ | 1200 |
5-in-1 High |
Global Fulfillment & Headquarters Support Manufactured with strict quality control by Jinan Golden Bridge Precision Machinery Co., Ltd. To shorten lead times for our most highly demanded standard models, we maintain strategic leased inventory nodes in the United States, Mexico, and Turkey. Note: All local dispatch operations, customized orders, and technical support are centrally verified and managed directly by our Jinan Headquarters engineering team. Please contact us to check real-time stock availability for your region.
Tip: Please let us know your required pressure (Bar/PSI) and application so we can match the perfect model for your facility.
